Deux Ex Machina…

Quasiparticles in motion: illustration of ghost polaritons in a calcite crystal being “launched” to record distances by a gold microdisk. (Courtesy: HUST)

Topics: Condensed Matter Physics, Modern Physics, Quantum Mechanics

The existence of ghost hyperbolic surface polaritons has been demonstrated by an international collaboration including researchers in China and the US. Based at Huazhong University of Science and Technology (HUST), National University of Singapore (NUS), National Center for Nanoscience and Technology (NCNST), and the City University of New York (CUNY), the team showed that the polariton – a hybrid light-matter quasiparticle – has a record-breaking propagation distance of three times its photon wavelength. This ghost polariton is an exciting discovery that has applications in sub-wavelength, low-loss imaging, sensing, and information transfer. The full study is described in Nature.

Previously, hyperbolic polaritons, which arise from the strong coupling of electromagnetic radiation to lattice vibrations (phonons) in anisotropic crystals, had only been observed in two forms: bulk polaritons and surface polaritons. Bulk, volume-confined, hyperbolic polaritons (v-HPs) have a real out-of-plane wavevector and hence can propagate within the material supporting them. Surface-confined hyperbolic polaritons (s-HPs), however, have an entirely imaginary out-of-plane wavevector, and so decay exponentially away from the crystal surface, a property called evanescence. The hyperbolic dispersion of these polaritons is the result of the crystal’s dielectric anisotropy, which results in hyperbolic isofrequency contours in k-space (momentum space) and concave wavefronts in real space.

Most studies on v-HPs and s-HPs have been performed in thin layers of van der Waals crystals. These crystals comprise stacks of covalently bound 2D layers that are held together by weak van der Waals forces. However, in such crystal layers, there is no control over the optical axis. This is the direction in which propagating light experiences no birefringence and it is typically aligned with the layers.

Ghost surface polaritons seen for the first time, Kirsty McGhee, Physics World
